ST100 Series Probus PA
Fluid Components International LLC 23
ST100 PROFIBUS PA (CLASSIC) DIAGNOSIS TABLE
PROFIBUS PA
DIAG_EXT
PROFIBUS PA Classic
DIAG (*2)
ST100 FCI Error or Status Description FCI Fault Type
# 0-6 DIA_MAINTENANCE
CORE reports SD card error. Either initialization (corrupt card) error, or
card became full (error while writing)
NF
# 0-7 FCI RESERVED (Not used) NF
# 1-0 FCI RESERVED (Not used) NF
# 1-1 FCI RESERVED (Not used) NF
# 1-2 FCI RESERVED (Not used) NF
# 1-3 FCI RESERVED (Not used) NF
# 1-4 FCI RESERVED (Not used) NF
# 1-5 DIA_HW_ELECTR
CORE unable to communicate with one or more FEs (PD_COMM_ER-
ROR)
F
# 1-6 FCI RESERVED (Not used) NF
# 1-7 DIA_MEASUREMENT CORE: averaged flow out of range of "Flow Min" or "Flow Max"
# 2-0 FCI RESERVED (Not used) NF
# 2-1 FCI RESERVED (Not used) NF
# 2-2 FCI RESERVED (Not used) NF
# 2-3 DIA_MEASUREMENT CORE: averaged temperature above "Temperature Max" F
# 2-4 DIA_MEASUREMENT CORE: averaged temperature below "Temperature Min" F
# 2-5 DIA_MEASUREMENT (Any) FE reports SENSOR_HEATER_1_SHORTED_FAULT F
# 2-6 DIA_MEASUREMENT (Any) FE reports SENSOR_HEATER_2_SHORTED_FAULT F
# 2-7 DIA_MEASUREMENT (Any) FE reports SENSOR_HEATER_1_OPEN_FAULT F
# 3-0 DIA_MEASUREMENT (Any) FE reports SENSOR_HEATER_2_OPEN_FAULT F
# 3-1 DIA_MEASUREMENT (Any) FE reports SENSOR_ABOVE_MAX_A_D_FAULT NF
# 3-2 DIA_MEASUREMENT (Any) FE reports SENSOR_BELOW_MIN_A_D_FAULT NF
# 3-3 FCI RESERVED (Not used) NF
# 3-4 DIA_MEASUREMENT (Any) FE reports SENSOR_ABOVE_MAX_FLOW_FAULT NF
