ST100 Series Probus PA
22 Fluid Components International LLC
ST100 ENGINEERING UNIT CODES TABLE
Description PROFIBUS PA Codes
TNPS (Metric Tonnes Per Second) 1326
TNPM (Metric Tonnes Per Minute) 1327
TNPH (Metric Tonnes Per Hour) 1328
TNPD (Metric Tonnes Per Day) 1329
VELOCITY FLOW UNIT CODES
SFPS (Standard Feet per Second) 1532
SFPM (Standard Feet per Minute) 1533
SFPH (Standard Feet per Hour) 1534
SFPD (Standard Feet per Day) 1535
NMPS (Normal Meters per Second) 1536
NMPM (Normal Meters per Minute) 1537
NMPH (Normal Meters per Hour) 1538
NMPD (Normal Meters per Day) 1539
TOTALIZER UNIT CODES
SCF (Standard Cubic Feet) 1053
NCM (Normal Cubic Meters) 1573
NL (Normal Liters) 1574
LB (Pounds) 1094
KG (Kilograms) 1088
TN (Metric Tonnes) 1092
PLENNUM (NOMINAL SIZE) UNIT CODES
In (Inches) 1019
mm (Millimeters) 1013
ST100 PROFIBUS PA (CLASSIC) DIAGNOSIS TABLE
PROFIBUS PA
DIAG_EXT
PROFIBUS PA Classic
DIAG (*2)
ST100 FCI Error or Status Description FCI Fault Type
# 0-0 DA_HW_ELECTR
CORE: If any of these errors occurs: I2C error, UART error, Mutex error,
watchdog reset
F
# 0-1 FCI RESERVED (Not used) NF
# 0-2 FCI RESERVED (Not used) NF
# 0-3 DA_HW_ELECTR
CORE unable to update process data (PD_NO_FE_DATA). Unable to
obtain/use data from any Active FEs
F
# 0-4 FCI RESERVED (Not used) NF
# 0-5 DA_HW_ELECTR CORE detects FRAM/SPI error F
