ST100 Series Probus PA

Fluid Components International LLC 25

CLASSIC DIAGNOSIS DEFINITIONS

Classic DIAGNOSIS Mnemonic Description

DIA_HW_ELECTR Hardware failure of the electronic

DIA_HW_MECH Hardware failure mechanics

DIA_TEMP_MOTOR Motor- temperature too high

DIA_TEMP_ELECTR Electronic temperature too high

DIA_MEM_CHKSUM Memory error

DIA_MEASUREMENT Failure in measurement

DIA_NOT_INIT Device not initialized (No self calibration)

DIA_INIT_ERR Self calibration failed

DIA_ZERO_ERR Zero point error (limit position)

DIA_SUPPLY Power supply failed (electrical, pneumatic)

DIA_CONF_INVAL Conﬁguration not valid

DIA_MAINTENANCE Maintenance required

DIA_CHARACT Characterization invalid

ST100 PROFIBUS PA (CONDENSED) DIAGNOSIS TABLE

PROFIBUS PA

DIAG_ EXT

PROFIBUS PA Condensed DIAG FCI Fault Type PROFIBUS PA Status

# 0.0 DIA_MAINTENANCE_ALARM F BAD (4): ALL

# 0-1 NF

# 0-2 NF

# 0-3 DIA_MAINTENANCE_ALARM F BAD (4): ALL

# 0-4 NF

# 0-5 DIA_MAINTENANCE_ALARM F BAD (4): ALL

# 0-6 DIA_MAINTENANCE NF GOOD (1): ALL

# 0-7 NF

# 1-0 NF

# 1-1 NF

# 1-2 NF

# 1-3 NF

# 1-4 NF

# 1-5 DIA_MAINTENANCE_ALARM F BAD (4): ALL

# 1-6 NF

# 1-7 DIA_INV_PRO_COND UNCERTAIN (5) 0, 2, 4
