ST100 PROFIBUS PA (CONDENSED) DIAGNOSIS TABLE

PROFIBUS PA

DIAG_ EXT

PROFIBUS PA Condensed DIAG FCI Fault Type PROFIBUS PA Status

# 2-0 NF

# 2-1 NF

# 2-2 NF

# 2-3 DIA_INV_PRO_COND F BAD (6) 0,1,2,3,4,5

# 2-4 DIA_INV_PRO_COND F BAD (6) 0,1,2,3,4,5

# 2-5 DIA_MAINTENANCE_ALARM F BAD (4) 0,2,4

# 2-6 DIA_MAINTENANCE_ALARM F BAD (4) 0,2,4

# 2-7 DIA_MAINTENANCE_ALARM F BAD (4) 0,2,4

# 3-0 DIA_MAINTENANCE_ALARM F BAD (4) 0,2,4

# 3-1 DIA_INV_PRO_COND NF UNCERTAIN (5) 0,2,4

# 3-2 DIA_INV_PRO_COND NF UNCERTAIN (5) 0,2,4

# 3-3 NF

# 3-4 DIA_INV_PRO_COND NF UNCERTAIN (5) 0,2,4

# 3-5 DIA_INV_PRO_COND NF UNCERTAIN (5) 0,2,4

# 3-6 NF

# 3-7 DIA_MAINTENANCE NF GOOD (1) ALL

# 4-0 DIA_MAINTENANCE_ALARM F BAD (4) 0, 2, 4

# 4-1 NF

# 4-2 DIA_MAINTENANCE NF GOOD (1) 0,2,4

# 4-3 DIA_MAINTENANCE NF GOOD (1) 0,2,4

# 4-4 DIA_MAINTENANCE_ALARM F BAD (4) 0, 2, 4

# 4-5 DIA_MAINTENANCE NF GOOD (1) ALL

# 4-6 DIA_MAINTENANCE NF GOOD (1) ALL

# 4-7 DIA_MAINTENANCE NF GOOD (1) ALL

# 5-0 DIA_MAINTENANCE NF GOOD (1) ALL

# 5-1 DIA_MAINTENANCE NF GOOD (1) ALL

# 5-2 DIA_MAINTENANCE NF GOOD (1) ALL

# 5-3 NF
