ST100 Series Probus PA
Fluid Components International LLC 27
CONDENSED DIAGNOSIS TABLE
Condensed DIAGNOSIS Mnemonic Description
DIA_MAINTENANCE Maintenance required
DIA_MAINTENANCE_ALARM Failure of the device or armature
DIA_MAINTENANCE_DEMANDED Maintenance demanded
DIA_FUNCTION_CHECK Device is in function check mode or in simulation or under
ocal control e.g. maintenance
DIA_INV_PRO_COND The process conditions do not allow to return valid values.
Set if a value has the quality Uncertain – Process related, in
maintenance, or Bad – Process related, no maintenance
PROCESS VARIABLES CODE (STATUS)
0 = VOLUMETRIC FLOW
1 = VOLUME (TOTALIZER)
2 = MASS FLOW
3 = MASS (TOTALIZER)
4 = VELOCITY FLOW
5 = TEMPERATURE
6 = PRESSURE
