Calibration Parameters Verication
The instrument uses a set of predetermined calibration parameters to process ow signals. Most of these parameters should not
change. A data package shipped with the instrument (typically on a CD-ROM) contains the ST75/ST75V Delta R Data Sheet. This
contains the calibration parameters stored in the ow transmitter at the factory. To verify that these parameters have not changed,
complete the following:
1. Identify the appropriate Delta R data sheets by serial number of the instrument.
2. Press [D] [ENTER] to examine each of the parameters. The [ENTER] key allows scrolling one message at a time. Use Table
4 below to record actual instrument parameters. Compare with the Delta R data sheet’s ST75/ST75V parameters.
Table 4. Diagnostic Test Sequence on Display
An issue may exist if parameters with an asterisk (*) have changed. Contact Customer Service if this is the case. If the parameters
have not changed, continue with the next section.
S/W Version: dR Min: T SpanIDA C 0:
Flow Factor: dR Max: T ZeroIDA C 0:
Cmin Flow: Cal Ref: T SpanIDA C 1:
Cmax Flow: Tcslp: T ZeroIDA C 1:
Eng Units : Tcslp 0: State 0:
Line Size 0: Tcslp 2: Switch Pt 0:
Line Size 1: Tot Menu: State 1:
Cmin Temp : Tot Flag: Switch Pt 1:
Cmax Temp : Totalizer: K factor 1:
Min Flow: Rollover Cnt: K factor 2:
Max Flow: Fix Pt Flag: K factor 3:
Density: Pulse Factor: K factor 4:
*C1 [1]: Pulse Out: I factor:
*C1 [2]: Hours: Temp Flag:
*C1 [3]: Sample Period: Out Mode:
*C1 [4]: dR Slope : Namurmode:
*C1 [5]: dR Off Set : Boxcar Max:
Break Pt: Refr Slope: RTD-SLP-385:
*C2 [1]: Refr Off Set: % of Range:
*C2 [2]: SpanIDAC 0: User Name:
*C2 [3]: ZeroIDAC 0: Shop Order #:
*C2 [4]: SpanIDAC 1: Serial No.:
*C2 [5]: ZeroIDAC 1: Mode l#:
