COM5, COM6：Serial Port with Box-header (2.0 mm)
Pin No. Signal Pin No. Signal
1 DCD 2 DSR
3 RXD 4 RTS
5 TXD 6 CTS
7 DTR 8 RI/+5V/+12V
9 Ground 10 NC
DIO1：Digital I/O Connector with Pin-header (2.54mm)
Pin No. Signal Pin No. Signal
1 DIO-Out3 2 DIO-In3
3 DIO-Out2 4 DIO-In2
5 DIO-Out1 6 DIO-In1
7 DIO-Out0 8 DIO-In0
9 Ground 10 +5V
