FEB-9455 User’s Manual
13
IDE1：HDD IDE Connector with Box-header (2.0mm)
Pin No. Signal Pin No. Signal
1 RESET# 2 Ground
3 Data 7 4 Data 8
5 Data 6 6 Data 9
7 Data 5 8 Data 10
9 Data 4 10 Data 11
11 Data 3 12 Data 12
13 Data 2 14 Data 13
15 Data 1 16 Data 14
17 Data 0 18 Data 15
19 Ground 20 NC
21 DMA REQ 22 Ground
23 IOW# 24 Ground
25 IOR# 26 Ground
27 IOCHRDY 28 Pull-down
29 DMA ACK# 30 Ground
31 INT REQ 32 NC
33 SA1 34 P66DETECT
35 SA0 36 SA2
37 HDC CS1# 38 HDC CS3#
39 HDD Active# 40 Ground
41 +5V 42 +5V
43 Ground 44 NC
INV1：Inverter Connector with Box header (2.50 mm)
Pin No. Signal
1 +12V
2 +12V
3 Ground
4 Ground
5 Inverter Enable
