FEB-9455 User’s Manual

LVDS1：LVDS Panel Signal with Wafer Connector (1.25 mm)

Pin No. Signal Pin No. Signal

1 Ground 2 Ground

3 L_DC3 4 L_DC3-

5 L_CLK0 6 L_CLK0-

7 L_DC2 8 L_DC2-

9 L_DC1 10 L_DC1-

11 L_DC0 12 L_DC0-

13 Ground 14 Ground

L_DC7

L_CLK1

19 L_DC6 20 L_DC6

L_DC5

L_DC4

25 Ground 26 Ground

27 LVDS Power 28 LVDS Power

29 LVDS Power 30 LVDS Power

Note：LVDS Power = +5V or +3.3V (Default)
