FEB-9455 User’s Manual
16
MIO1：Multi-IO Connector with Box-header (2.54 mm)
Pin No. Signal Pin No. Signal
1 DCD#4 2 DSR#4
3 RXD#4 4 RTS#4
5 TXD#4 6 CTS#4
7 DTR#4 8 RI#4
9 DCD#3 10 DSR#3
11 RXD#3 12 RTS#3
13 TXD#3 14 CTS#3
15
DTR#3
16
RI#3
17
DCD#2/DT-
18
DSR#2
19 RXD#2/DT+ 20 RTS#2
21
TXD#2/422R+
22
CTS#2
23
DTR#2/422R-
24
RI#2
25 DCD#1 26 DSR#1
27 RXD#1 28 RTS#1
29 TXD#1 30 CTS#1
31 DTR#1 32 RI#1
33 F_KCLK 34 F_KDAT
35 L_MCLK 36 L_MDAT
37 DIO_OUT0# 38 DIO_IN0
39 L_TX- 40 L_TX+
41 L_P4&P5C 42 L_RX-
43 L_RX+ 44 L_P7&P8C
45 LED0# 46 LED1#
47 5VHSYNC 48 5VVSYNC
49 5VDDCCLK 50 5VDDCDATA
51 Ground 52 VGA_RED
53 Ground 54 VGA_GREEN
55 Ground 56 VGA_BLUE
57 Ground 58 HDD_LED#
59 FA-OUT-L 60 FA-OUT-R
