CHAPTER 3
TWIN ROTOR MIMO SYSTEM
PCL – 812 Card Settings Installation and Commissioning
33-007-03-4
JP8, JP9 - D/A Internal Reference, A/D Maximum Input Voltage Selection
10 5
JP8OOO
JP9OOO
Depending on the specification and configuration of your PC you may need to change the
Base Address and Wait State settings.
None of the other settings need to be changed
.
3.3 SWITCH SW1 SETTINGS FOR 8 BIT FULL LENGTH PCL - 812
BOARD
I/O Address Range (hex
and decimal)
SW1 Switch position
123456
200-20F (512-527 Dec) ON ON ON ON ON X
210-21F (528-543 Dec) ON ON ON ON OFF X
220-22F (544-559 Dec)
*
ON ON ON OFF ON X
230-23F (560-575 Dec) ON ON ON OFF OFF X
300-30F (768-783 Dec) OFF ON ON ON ON X
3F0-3FF (1008-1023 Dec) OFF OFF OFF OFF OFF X
Note: An “X” in the table above means that this switch is not used.
☞
