CHAPTER 6
TWIN ROTOR MIMO SYSTEM
Test Sequence Installation and Commissioning
33-007-06-2
ACTION RESULT
7. Turn the horizontal axis
locking screw to stop rotation
about the horizontal axis.
8. Drag the slider on the
horizontal motion motor
speed/direction bar one
position to the right.
Drag it further to the right.
The horizontal motion motor starts to rotate
clockwise viewed from the front.
The rotational speed increases and the rotor
starts to rotate about a vertical axis with
additional speed.
9. Drag the slider on the
horizontal motion motor
speed/direction bar one
position to the left.
Drag it further to the left.
The horizontal motion motor starts to rotate
counter clockwise viewed from the front.
The rotational speed increases and the rotor
starts to rotate about a vertical axis with
additional speed.
Always be prepared to press the round red STOP button to cut the power to
the system if the rotational speed becomes excessive
.
When you have completed the commissioning and test of your MIMO system, refer to the
manual “Getting Started” – 33-007-1M5 to use the system under the control of MATLAB
and the real time control software.
