4. isolators before setting on a flat surface. This will insure the isolators from not
being damaged.
Noise Isolators 225i
5. Make sure the cutting block is on a stable surface before performing any
maintenance or repair work.
To remove the cutting block from the cabinet on model 225Ci:
1. Remove the 4 Allen screws that secure the cutting block to the noise isolators on the
cabinet.
Noise Isolators 225Ci & 225Mi
2. Lift the cutting block with the motor out of the cabinet and place on a flat surface to
protect the cutting cylinders.
3. Make sure the cutting block is on a stable surface before performing any
maintenance or repair work.
Motor
• The motor shaft turns the gear drive.
• If the motor gears or gearbox cover are defective, they can be replaced separately.
• If the motor is defective, it must be replaced. Note: If the motor shaft is broken /
defective the motor will have to be replaced.
