DUOX VEO XS MONITOR 7
TECHNICAL FEATURES
Power (no polarity)
Consumption
18 Vdc
- in standby: 25 mA
- maximum: 370 mA
WITH Induction loop
NO Induction loop
OSD TFT Screen 4.3
”
Resolution
Humidity
(0% - 90%):
Hor.: 480 Line TV
Ver: 272 Line TV
Operating Temperature
[-5, +40 °C] / [23, 104 °F]
- in standby: 25 mA
- maximum: 770 mA
Number of terminals per residence
3
Each monitor's address: 6 digits 000001...999999
Monitor Dimensions:
165 x 125 x 21mm - 6.5” x 4.9” x 0.8” - (Height x Width x Depth)
PRODUCT DESCRIPTION
VEO XS Monitor
Buttons
Potentiometer
Leds
Audio induction loop. It comes identifi ed with this label (according to model).
· It includes a hearing loop that interacts with auditory devices for the hearing
impaired.
Note: For hearing devices with manual selection modes, these should be
confi gured in Digital Mode.
