FERMOD KIT 5000 - Page 27

Kit5000_GB-A
7
4
Rotate 90° to the motor.
5
Mount the motor
on it’s bracket.
!
6
Fix the belt guide (A).
A
- 27 -
!
Fermatic
2120-2130-2150
2320-2420
Fermatic
3430
3530-7530
. Belt mounting and tighten
Follow step 6.5
page 13
Follow step 7.4
page 24
90°
