FERMOD KIT 5000 - Motor

Kit5000_GB-A
- 18 -
MOTOR
7.3
The motor mounting depends on Manual Fermatic system (3430 or 3530/7530) and
butt model mounted onto the rail.
There are 5 dierent ways to mount the motor:
CASE N°2
page 20
A
CASE N°3
page 21
D
C
B
CASE N°5
page 23
CASE N°1
page 19
CASE N°4
page 22
G
F
E
OR
3430
3530
7530
3530
7530
90° MOTOR MOUNTING See page 26
LEFT SIDE MOTOR MOUNTING See page 28
Opening
side
Opening
side
Opening
side
Opening
side
Opening
side
Opening
side
