FERMOD KIT 5000 - Page 19

Kit5000_GB-A
d
Sticker
3430
c
- 19 -
CASE N°1 - FERMATIC 3430
A
B
6
!
!
BLOCK
DO NOT
BLOCK
M8
A B
D
M6
OK
A B
C
D
1 - Right side of the rail, remove the screw
of the end bracket.
2 - Replace the screw of the end bracket with
a screw and the spacer (B) from small bag
(M8). Block screw and spacer.
3 - Left side of the end bracket, mount spacer (A)
with the second screw from (M8) into the
rst hole of the rail.
Do not block.
4 - Engage a nut and a washer from small bag
(M8) on screw (C).
5 - Tip the motor bracket to engage the screw (C)
in the slot (c) and position the motor bracket
by engaging the screw (D) into the hole (d) of
the bracket.
6 - Push the screw (C) in the slot (c).
Block spacer (A) and nut of the screw (C).
7 - Block the nut of screw (D).
PUSH THE DOOR LEFT SIDE
!
24
17
17
!
