Main engine speci cations
Type F 136 E
Number of cylinders 8 - V 90°
Cylinder bore mm 92 (3.622 in.)
Piston stroke mm 81 (3.189 in.)
Total displacement cm
3
4308 (262.788 cu.in.)
Compression ratio 11,3 : 1
(*) Max power: (2002/80B/CE) kW 360,3 (490 HP)
Corresponding r.p.m. rpm 8500
Maximum torque (2002/80B/CE) Nm 465
Corresponding r.p.m. rpm 5250
(*) A slight boosting is attainable at top speed.
Transmission ratios
Differential bevel Total transmission ratio
Gear ratios gear pair ratio (engine/wheel rev)
1 46 / 14 = 3,29 4,30 (10/43) 1 14,13
2 41 / 19 = 2,16 2 9,28
3 37 / 23 = 1,61 3 6,92
4 33 / 26 = 1,27 4 5,46
5 30 / 29 = 1,03 5 4,45
6 31 / 38 = 0,82 6 3,51
R 41 / 15 = 2,73 R 11,75
Performance
0-100 km/h 0-400 m 0-1000 m Max. speed.
F1 gearbox 4,0 sec. 11,95 sec 21,60 sec over 315 km/h
(195.74 mph)
Mechanical gearbox 4,0 sec. 12,00 sec 21,65 sec over 315 km/h
(195.74 mph)
