Emergency tyre repair and in ation kit
Emergency tyre repair and in ation kit
In the event of a puncture or low pressure
of a tyre, the kit can be used to repair and/
or in ate the tyre suf ciently to continue
the journey safely.
The kit includes a replaceable cartridge
A containing the puncture repair uid,
an electric compressor B equipped with
a pressure gauge C, a switch D and two
unions for tyre repair and/or in ation.
After using the repair kit, the vehicle
must however be considered to be
in an emergency situation: drive with the
utmost care (maximum permissible speed
80 km/h).
The kit is to be used to temporarily repair
only one tyre punctured by small-sized
objects: the kit may be unuseful in the case of
large punctures or tearing.
Keep the kit in its box and out of
children’s reach. Do not inhale or
swallow the uid contained in the cartridge
Toolkit
Toolkit bag
This is housed in the luggage compartment.
This is housed in the luggage compartment.
It contains the necessary tools to allow
you to make a rst repair in the event of a
failure:
• set of  at wrenches
• insulated cutting pliers
• screwdriver for cross-head/slotted screws
• tow hook
• set of spare bulbs and fuses.
set of spare bulbs and fuses.
and avoid contact with the skin and eyes.
The repaired tyre must be replaced as soon
as possible and the workshop personnel
must be informed that the tyre was treated
with tyre repair uid.
The sealant contained in the cartridge in
the tyre repair kit may damage the sen-
sor tted inside the wheel rim on vehicles
equipped with the tyre pressure monitor-
ing system. In these cases, always have the
sensor replaced by an authorised
Ferrari
Service Centre.
No kit is provided for the spare wheel.
In the event of a tyre puncture, proceed as
follows.
Open the box and take out the
compressor. Remove the electrical cable
with the connector F for the power
socket.
Insert the connector F into the power
socket, on the central tunnel.
