Electronic Control Units
The gure shows the location of all the
ECUs installed on the vehicle.
Motronic (one per bank)
Instrument panel
Air conditioning/heating system
Shock absorber calibration adjustment
ABS-ASR
Airbag
Alarm system
Power windows
F1 gearbox (for cars with F1 gearbox)
Electronic differential
Immobilizer
Door locking system
Windscreen wipers
Blinking and hazard lights
Tyre pressure monitoring system
(optional)
Bluetooth™ (optional)
