20 ferrismowers.com
rear of the rider and push it towards the rear tire. Repeat
this process for the other side of the rider.
4. Disengage the parking brake. The rider can now be
pushed by hand.
5. After moving the rider, close the bypass valve (run
position) (C) by pushing the transmission release lever
towards the center of the machine and then pushing it
towards the front of the rider. Repeat this process for the
other side of the rider.
Note:Both transmission release levers must be in the same
position.
Attaching a Trailer
The maximum weight of a towed trailer should be less than
200 lbs (91 kg). Secure the trailer with an appropriately sized
clevis pin (A, Figure19) and clip (B).
19
Excessive towed loads can cause loss of traction and loss of
control on slopes. Reduce towed weight when operating on
slopes. The surface being driven on greatly impacts traction
and stability. Wet or slippery surfaces can greatly reduce
traction and the ability to stop or turn. Carefully evaluate
the surface conditions before operating the unit and trailer,
and never operate on slopes greater than 5°. SeeSlope
OperationandTowed Equipment (Ride-On Units)in the
safety section of this manual for additional safety information.
Storage
Temporary Storage (30 Days or Less)
Remember, the fuel tank will still contain some gasoline, so
never store the unit indoors or in any other area where fuel
vapor could travel to any ignition source. Fuel vapor is also
toxic if inhaled, so never store the unit in any structure used
for human or animal habitation.
WARNING
Never store the unit, with gasoline in engine or fuel tank,
in a heated shelter or in enclosed, poorly ventilated
enclosures. Gasoline fumes may reach an open flame,
spark or pilot light (such as a furnace, water heater, clothes
dryer, etc.) and cause an explosion.
Handle gasoline carefully. It is highly flammable and
careless use could result in serious fire damage to your
person or property.
Drain fuel into an approved container outdoors away from
open flame or sparks.
Here is a checklist of things to do when storing your unit
temporarily or in between uses:
• Keep the unit in an area away from where children
may come into contact with it. If there’s any chance of
unauthorized use, remove the spark plug (s) and put in a
safe place. Be sure the spark plug opening is protected
from foreign objects with a suitable cover.
• If the unit can’t be stored on a reasonable level surface,
chock the wheels.
• Clean all grass and dirt from the mower.
Long Term Storage (Longer Than 30 Days)
Before you store your unit for the off-season, read the
Maintenance and Storage instructions in the Safety Rules
section, then perform the following steps:
1. Drain crankcase oil while engine is hot and refill with a
grade of oil that will be required when unit is used again.
2. Prepare the mower deck for storage as follows:
a.) Remove mower deck from the unit.
b.) Clean underside of mower deck.
c.) Coat all bare metal surfaces with paint or light coat of
oil to prevent rusting.
3. Clean external surfaces and engine.
4. Prepare engine for storage. See engine owner’s manual.
5. Clean any dirt or grass from cylinder head cooling fins,
engine housing and air cleaner element.
6. Cover air cleaner and exhaust outlet tightly with plastic or
other waterproof material to keep out moisture, dirt and
insects.
7. Completely grease and oil unit as outlined in the
Lubrication section.
8. Clean up unit and apply paint or rust preventative to any
areas where paint is chipped or damaged.
9. Be sure the battery is filled to the proper level with water
and is fully charged. Battery life will be increased if it is
removed, put in a cool, dry place and fully charged about
once a month. If battery is left in unit, disconnect the
negative cable.
10. Drain fuel system completely or add a gasoline stabilizer
to the fuel system. If you have chosen to use a fuel
stabilizer and have not drained the fuel system, follow
all safety instructions and storage precautions in this
