11 / 24Festo 7DZF / DZHb_en
Item Designation Note
1 Hex nut For piston rod from size DZH-25-…
2 Piston rod seal
3 Bearing bush
4 Bearing cap
5 Self-tapping screw Use screw locking agent
6 O-ring
7 Serrated ring Only from size DZH-32-…
8 Regulating screw
9 O-ring
10 Cushioning seal
11 Washer Only DHZ-25-…-PPV-A and DHZ-25-…-PPV-A-S6
12 Piston rod with male thread
13 Hollow piston rod with male thread Only with DZH-…-S20
14 Groove ring
15 Piston
16 Guiding band
17 Threaded coupling
18 Piston rod extension Only with DZH-…-S2, use screw locking agent
19 Hollow piston rod extension Only with DZH-…-S20, use screw locking agent
20 Cylinder barrel
21 End cap
22 Cushioning boss Only from size DZH-50-…
23 Groove ring Only from size DZH-50-…
24 Piston Only from size DZH-50-…
25 Magnet Only from size DZH-32-…
26 Guiding band Only from size DZH-50-…
