7 Tools
This section provides an overview of the tools and accessories required to repair and maintain the cylinder with piston
rod.
7.1 Standard tools
The following standard tools among others are required to repair the cylinder with piston rod:
• Screwdriver
• Wrench
• Torque wrench (see tables in the corresponding repair steps for values)
7.2 Special tools
The following special tools are required to repair and service the cylinder with piston rod:
Designation Additional information Illustration
Mounting sleeve for piston rod The mounting sleeve for piston rods for
protecting the piston rod seal and the bearing
in the bearing cap while the repair is being
carried out must be produced by the customer.
The schematic diagram is included in
the information brochure "Accessories,
equipment and tools" (7Accessories_a_en).
Documents
Further information on the special tools and schematic diagrams is included in the information brochure "Accessories,
equipment and tools" (7Accessories_a_en). This can be found in the online spare parts catalogue on the Festo
website (http://spareparts.festo.com/xdki/data/SPC/0/PDF_SAFE/Hilfsmittel.pdf ).
8 Liability
The General Terms and Conditions of Sale of Festo AG & Co. KG, which can be viewed on the Festo website
(www.Festo.com), apply.
