9 / 24Festo 7DZF / DZHb_en
Item Designation Note
1 Hex nut For piston rod with male thread
2 Piston rod seal
3 Bearing bush
4 Self-tapping screw Use screw locking agent
5 O-ring
6 Threaded pin
7 Bearing cap
8 Seal
9 Piston rod with male thread
10 Piston rod with female thread
11 Piston rod with male thread, hollow S20 only
12 Piston
13 Washer Not S2, not S20
14 Hex nut Not S2, not S20
15 Piston rod with male thread S2 only, use screw locking agent
16 Piston rod with female thread S2 only, use screw locking agent
17 Piston rod with male thread, hollow S20 only, use screw locking agent
18 Cylinder barrel
19 End cap
The feature S6 indicates the design/material variants and is of little or no importance for the order of the repair steps.
