Feature Code Type
– AG Integrated pressure gauge
– A4 Adapter for EN pressure gauge ¼, without pressure gauge
– AD1 Pressure sensor with display, M8 plug, PNP, 3-pin
– AD2 Pressure sensor with display, M8 plug, NPN, 3-pin
– AD3 Pressure sensor with display, plug M12, PNP, 4-pin, ana-
logue output 4…20 mA
Pressure gauge / pressure
gauge alternative
1)
– AD4 Pressure sensor with display, plug M12, NPN, 4-pin, ana-
logue output 4… 20 mA
– PSI psi scaling
– MPA MPa scaling
Alternative pressure gauge
scaling
1)
– BAR bar scaling
– MP1 Sub-D, 9-pin, screw terminal, without cable
Enable signals static (EN1=24 V, EN2=24V)
– MP3 Sub-D, 9-pin, screw terminal, without cable
Enable signals static (EN1=0 V, EN2=24V)
Cross-circuit detection possible
Multi-pin plug socket
1)
– MP5 Sub-D, 9-pin, screw terminal, without cable
Enable signals static (EN1=0V,EN2=24V)
Galvanic isolation of enable signal from the supply voltage
Type of mounting
1)
– WPB Mounting bracket for large mounting spacing
UL certification
1)
– UL1 UL certification for Canada and USA
Alternative flow direction
1)
– Z Flow direction from right to left
1) optional
Tab. 2 Product overview
5.2 Function
The product is a safe, redundant mechatronic system in accordance with the requirements of EN ISO
13849-1+2. The safe venting pneumatic safety function is guaranteed even in the event of an error in
the valve (e.g.due to wear or contamination). Through its electrical connection (NECA multi-pin plug
socket Sub-D, 9-pin), the product receives secure enable signals (EN1/EN2) from commercially-avail-
able electronic or electromechanical safety relay units, which monitor the machine’s protective
devices (e.g.emergency stop, light curtain, electric door switch on the protective housing, etc.).
Product Overview
8 Festo — MS6-SV-...-E-10V24 — 2019-10d
