1. Summary of components
1-3
Festo P.BE-CPVSC-EN en 0112NH
1.1 Description of variants
Festo assists you in solving your automation tasks at machine
level with valve terminals.
Due to its compact structure the CPV-SC valve terminal can
be mounted close to the actuators to be controlled. Short
compressed air tubing can therefore be used. With shor t
compressed air tubing, system losses can be minimized and
the times required for pressurizing and exhausting the tubing
can be minimized. This enables very compact valves with high
flow rate to be used, therefore helping to reduce costs.
CPV-SC valve terminal
with MP connection
This CPV-SC valve terminal is available with 4, 8 or 12 CP
valve sub-bases. The valve solenoid coils are connected
centrally via the multipin connection. This is available in the
following designs:
– 15-pin Sub-D plug
– 20-pin flat cable.
1.2 Description of components
Sizes of the CPV-SC valve terminals
The CPV-SC valve terminal is available in the following sizes:
CPVSC1 10 mm Micro valves
