1. Summary of components
1-4
Festo P.BE -CPVSC-EN en 0112NH
Identification code
With the identification code (I.C.) you can ascertain the equip-
ment fitted on your CPV-SC valve terminal. The code is
printed on the front below the manual overrides.
I.C.
Pneumatic components
Valve sub-bases
M 5/2-way valve, single-solenoid
J 5/2-way valve, double-solenoid. This valve consists of two valve plates and therefo re
occupies two valve locations. The ”control valve” is marked with j 12, the ”work valve” with
Ident. code J.
N 3/2-way va lves, single- solenoid, neut ral position open
K 3/2-way va lves, single- solenoid, neut ral position closed
D 2/2-way valve s, single-solenoid, neut ral position closed
Separator plate with additional pressure supply
T Compressed air channel (1) blocked
S Compressed air channel (1) and exhaust air channel (3/5) blocked
Additional pressure supply
U Additional supply of compressed air (1) and additional exhaust removal (3/5)
Blanking plate
L Plate without valve function for reser ving a valve location
Further information on the valve plates can be found in
Appendix A.
