Festo Smart cubic CPV-SC Series User Manual

1. Summary of components
1-7
Festo P.BE-CPVSC-EN en 0112NH
On the CPV-SC valve terminal with multipin connection you
will find the following electrical connecting and display el-
ements:
1
2
3
1 Multipin connection with 20-pin
flat cable or 15-pin Sub-D multipin
connection
2 Valve location identification label
3 Yellow LED, signal status displays
per pilot solenoid
Fig. 1/3: Electrical connecting and display elements of the CPV-SC valve terminal with
MP connection
