1. Summary of components
1-6
Festo P.BE -CPVSC-EN en 0112NH
Connecting, display and operating elements
On the CPV-SC valve terminal you will find the following con-
necting, display and operating elements:
1
4 23
1
Manual override (per pilot solenoid,
locking and non-locking)
2 Exhaust connections (3/5, 82/84)
3 Work connections (2, 4) per valve
4 Supply connections (1, 12/14)
Fig. 1/2: Pneumatic connecting and operating elements of the CPV-SC valve terminal
