Technical data
Output, general
Repetition accuracy [%FS] ± 0.3
Temperature coefficient [%FS/K] Typ. ± 0.05
Tab. 11
Switching output
Switch-on time [ms] Typ. 1, with filter time constant = Off (default)
Switch-off time [ms] Typ. 1, with filter time constant = Off (default)
Max. output current [mA] 100
Capacitive load maximum DC [nF] 100
Voltage drop [V] Max. 1.2
Inductive protective circuit Present
Tab. 12
Output, additional data
Short circuit current rating Yes
Overload protection Present
Tab. 13
Electronics
Operating voltage range DC [V] 18…30
No-load supply current [mA] < 11
Ready-state delay [ms] < 30
Reverse polarity protection All connections against one other
Tab. 14
Electromechanics
Electrical connection Cable 3-wire, open end
Max. permissible line length [m] 30, with IO-Link 20
Cable sheath material PVC
Tab. 15
