Technical data
19
Mechanics
Mounting position Any, avoid condensation accumulation in the
sensor
Housing material Reinforced PA
Key material POM
Tab. 16
Immission/Emission
Storage temperature [°C] –20…+80
Degree of protection in accordance with
EN60529
IP40
Protection class in accordance with
DIN VDE 0106-1
III
Shock resistance in accordance with
EN60068-2
30 g acceleration with 11 ms duration (half-sine)
Vibration resistance in accordance with
EN60068-2
10…60Hz: 0.35mm/
60…150Hz: 5g
Pollution degree 3
Tab. 17
SPAE -B2 -B11 -V025 -V05 -V1
Pressure
gauge
range
[MPa] –0.1…0.1 –0.1…1 0…–0.025 0…–0.05 0…–0.1
[bar] –1…1 –1…10 0…–0.25 0…–0.5 0…–1
[psi] –14.5…14.5 –14.5…145 0…–3.625 0…–7.25 0…–14.5
Overload
range
[MPa] –0.1…0.5 –0.1…1.5 –0.1…0.1 –0.1…0.2 –0.1…0.5
[bar] –1…5 –1…15 –1…1 –1…2 –1…5
[psi] –14.5…72.5 –14.5…217.5 –14.5…14.5 –14.5…29 –14.5…72.5
Tab. 18
