Commissioning
13
2. Press and hold the operating key to accept the teach pressure as the switching point.
The display alternates between ‘P1’ and the value of the set switching point while the operating
key is pressed.
Ä
The teach pressure is applied as the switching point.
3. Release the operating key.
Ä
The RUN mode is active.
Setting switching point with two teach pressures
1. Apply the first teach pressure to the sensor.
2. Press and hold the operating key to accept the teach pressure as the switching point.
The display alternates between ‘tP’ and the value of the set switching point while the operating
key is pressed.
Ä
The teach pressure is set as the switching point.
3.
Release the operating key.
4.
Apply the second teach pressure to the sensor.
5.
Press and hold the operating key to accept the teach pressure as the switching point.
The display alternates between ‘tP’ and the value of the set switching point while the operating
key is pressed.
Ä
The teach pressure is set as the switching point.
6.
Release the operating key.
Ä
Switching function F1 only: ‘P1’ and the value of the switching point P1 briefly appear.
Ä
The RUN mode is active.
7.4 Replicating parameters
Requirements:
– The previously configured sensor (master sensor) is ready for operation and is in RUN mode.
– The switching output on the device sensor is configured to PNP and is in an unswitched status; the
LED is off.
–
The master sensor and device sensor have the same design with reference to the parameters,
i.e.they have the same device ID.
– The master sensor is connected to the device sensor and the power supply
è
Fig. 7.
– Parameterisation of the device sensor must not be blocked via IO-Link.
