Festo SPAE - IO-Link; 11.1 Ambient conditions UL;CSA

20
Festo — SPAE — 2022-12c
Technical data
SPAE -P025 -P05 -P1 -P2 -P6 -P10
Pressure
gauge
range
[MPa] 0…0.025 0…0.05 0…0.1 0…0.2 0…0.6 0…1
[bar] 0…0.25 0…0.5 0…1 0…2 0…6 0…10
[psi] 0…3.625 0…7.25 0…14.5 0…29 0…87 0…145
Overload
range
[MPa] –0.1…0.1 –0.1…0.2 –0.1…0.5 –0.1…0.6 –0.1…1.5 –0.1…1.5
[bar] –1…1 –1…2 –1…5 –1…6 –1…15 –1…15
[psi] –14.5…
14.5
–14.5… 29 –14.5…
72.5
–14.5… 87 –14.5…
217.5
–14.5…
217.5
Tab. 19
IO-Link
IO-Link protocol V1.1
IO-Link profile Smart Sensor Profile
Function classes: 0x8000, 0x8001, 0x8002,
0x8003, 0x8004
Communication mode COM2 (38.4 kbaud)
Port type A
Process data length IN 2 bytes
Process data content IN Pressure monitoring BDC1 (BinaryDataChannel1)
Pressure monitoring BDC2 (BinaryDataChannel2)
Pressure measurement value PDV 14 bit (Process-
DataVariable)
IODD and IO-Link device description
è
www.festo.com
Tab. 20: General IO-Link specification
11.1
Technical data for UL/CSA certification
Ambient conditions UL/CSA
Pollution degree 2
Operating temperature 0…50 °C/ 32…122 °F
Relative humidity 0…100%
For use in wet locations No
Tab. 21: Ambient conditions UL/CSA
