Festo SPC11 2018-12b English4
2 Connecting and display elements
12 3
4
5
6
7
8
1
Control: operating voltage
connection and I/O coupling
2 Valve: Valve connection
3 Display
4 Operating buttons
5 Type plate
6 Groove for identification
signs (type IBS 6x10)
7 Measuring system
connection (here type
SPC11-POT-TLF)
8 Earth (ground) connection
