your warranty claims by always using original Fes-
tool accessories and Festool consumable material!
The order numbers of the accessories and tools can
be found in the Festool catalogue or on the Internet
under "www.festoolusa.com".
Saw blades, other accessories
In order to saw different materials quickly and
cleanly, Festool offers saw blades for all applica-
tions that are specially designed for your Festool
jigsaw.
Sawing with special base runners
The special base runners protect high-quality sur-
faces against scratches and scores.
X Press in the base runner at position [7-1] .
X At the same time, push the base runner for-
wards.
X Mount another base runner and push it to the
rear until it engages.
Sawing with the angle table
The angle table WT-PS 400 is used for cutting pipes
or interior and exterior angles up to 45°.
Dust extraction is not possible when sawing
with the angle table!
Installing the angle table
X Remove the saw base [1-11] , (see chapter ).
X Position the angle table against the saw base
support.
X Close the lever [1-9] .
Ensure that the angle table is firmly seated in the
guide.
Setting the angle
X Turn the adjusting wheel [8-1] to select the re-
quired angle.
You can select the angles -45°, 0° and +45° on the
scale [8-2] .
WARNING
Risk of injury, electric shock
X Always pull the mains plug out of the socket be-
fore performing any type of work on the ma-
chine!
7
7-1
WARNING
Sawing cutting depths
Risk of injury
X Select the saw blade length and cutting depth so
that the saw blade remains plunged in the work-
piece.
