16
L
For 90° cuts, we recommend setting the angle
table to a small negative angle to guarantee
smooth operation.
Sawing with the adaptation table
The adaptation table ADT-PS 400 is used for attach-
ing your jigsaw to the Festool guide rail, the circle
cutter KS-PS 400 and the CMS modular system.
With guide rail and circle cutter:
do not ex-
ceed max. material thickness of 20 mm and
always use cross-set saw blades (FSG).
Installing the adaptation table
X
Remove the saw table
[1-11]
, (see chapter-
Changing saw table).
X
Mount the adaptation table
[9-1]
on the saw ta-
ble support.
X
Close the change lever
[1-9]
.
Ensure that the adaptation table is firmly seated in
the guide.
L
Use the extractor connector
[1-8]
also with the
adaptation table.
Adaptation to the guide rail FS 2
The Festool guide system FS 2 (Fig.
[10]
) makes it
much easier to manufacture straight precision
cuts.
X
Place the jigsaw with attached adaptation table
[9-1]
on the guide rail.
