3938
3
Trim stop Cross stop
Trims of 22 – 70 mm width can be quickly positioned and
fixed centrally using the trim stop – ideal for rack joints.
(For DOMINO DF 500 and DOMINO XL DF 700)
Repetitive hole centres of 100 – 205 mm can be easily
transferred using the cross stop – without scribing the
workpiece.
(For DOMINO DF 500 and DOMINO XL DF 700)
DETAILS on working with the cross stop can be found
in the example applications on pages 74 and 79.
DETAILS on working with the trim stop can be found
in the example applications on page 50.
