Festool DOMINO User Manual

DF 500 DF 700
40
DF 700 support surface extensionDF 500 additional stop
The support surface extension provided with the DF 700
allows the contact area to be extended for routing on
the edge of the workpiece and the machine is thus more
reliably guided.
The additional stop provided with the DF 500 increases
the contact area and reduces the lateral distance of
the stop catches to the DOMINO centre from 37 mm
to 20 mm. This allows precise positioning of narrow
workpieces.
DETAILS on working with the additional stop and the
support surface extension can be found in the example
applications on page 76.
2016_FES_DOMINO_Book_GB-en.indb 40 03.03.16 12:13

Festool DOMINO Specifications

General

Motor Power	420 W
Dust Extraction Connection Diameter	27 mm
Power Source	Corded Electric
Cutting Depth	15 mm, 20 mm, 25 mm, 28 mm
Cutter Diameter	5 mm, 6 mm, 8 mm, 10 mm
