Set the width of the trim stop to the thickness of your spindle
by adjusting the guide in the parallel side fence to the correct
dimension using the scale and the green rotary wheels. In
this example, we are working with 30 x 30 mm rectangular
spindles.
Using the spindle as a guide, ensure that the trim stop dimension
fits perfectly; make further adjustments if necessary.
To process a 6 x 40 mm domino as in this example, use the
6 mm router (6 mm dominos can only be processed with
the DF 500). For details on changing the router, see chapter
1.4.4, page 18.
Mount the trim stop onto the DOMINO joining machine
according to the operating instructions.
2016_FES_DOMINO_Book_GB-en.indb 51 03.03.16 12:13

Festool DOMINO Specifications

General

Motor Power	420 W
Dust Extraction Connection Diameter	27 mm
Power Source	Corded Electric
Cutting Depth	15 mm, 20 mm, 25 mm, 28 mm
Cutter Diameter	5 mm, 6 mm, 8 mm, 10 mm
