Go to fetco.com for the latest versions of all information Page 15 User Guide & Operator instructions P194Re0 November 2020
ITEM Qt
y
PART NO DESCRIPTION Drawin
g
number 1101.00569.00
1 1 1111.00105.00 WELDMENT BODY, CBS-1221
2 7 1084.00051.00 NUT, HEX LOCK WASHER, #8-32, 18-8 ST. STL.
3 6 1073.00021.00 FOOT, RUBBER, 1/4-20
4 2 1084.00017.00 NUT, HEX, 1/4"-20
5 REF 1 Reference ELECTRICAL COMPONENT LATTICE, CBS-1200
5-1 1 1023.00360.00 ELECTRICAL MOUNTING LATTICE, AIR POT
5-2 1 1052.00023.00 EUROSTRIP HE16 TERM. BLOCK, 4 POLE, 63 AMP, 18-8 AWG
5-3 2 1082.00056.00 SCREW, #8-11 X 1" PAN HD PHIL, THREAD FORMING
5-4 1 1058.00024.00 SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
5-5 1 1057.00043.00 SOLENOID VALVE, 5.5L/min, 180 DEG, 24VDC
5-6 2 1082.00010.00 SCREW, PAN HD. PHIL. MACH., M4x10 ZINC-PLATED
5-7 1 1058.00055.00 USB CONNECTOR
5-8 1 1052.00001.00 POWER SUPPLY, 90-264VAC/24VDC, 1.8
A
5-9 4 1082.00132.00 SCREW, PAN HD. PHIL. THREAD-FORMING, #4-20x5/16"LG.
6 1 1065.00009.00 GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
7 1 1044.00012.00 LABEL GROUND, CE
8 1 1102.00164.00
A
DAPTER ASSY, 3/4" BSP X 1/4 SAE FLARE
9 1 1102.00453.00
A
SSEMBLY, FRONT PANEL, CBS-1220
10 3 1023.00361.00 SPACER, UNTHREADED, 1/2"OD X 3/8" LONG
11 3 1082.00115.00 SCREW, #6 x 3/8" LG., SLOTED HEX HD. WASHER
12 1 1071.00055.00 FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
13 1 1084.00048.00 JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
14 1 1102.00113.00 SWITCH, REED, ASSEMBLY
15 2 1029.00006.00 NUT, FINGER KNURLED, #4-40
16 REF 1 1102.00456.00 QUICK CONNECT SPRAY HEAD ASSEMBLY, SMALL, RETROFIT
16-1 1 1023.00353.00 BASE, QUICK CONNECT SPRAY HEAD, RETROFIT
16-2 1 1102.00479.00
A
SSEMBLY, CASCADE SPRAY DOME, NEXT GEN
(
BLUE
)
16-3 1 1023.00342.00 QUICK CONNECT CLIP
16-4 1 1057.00076.00 VALVE ASSEMBLY, COMPLETE, NG, DELTROL
17 1 1024.00063.00 O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUN
A
-N, DURO-
A
50
18 4 1083.00010.00 WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
19 4 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW
20 1 1024.00065.00 CONNECTOR, SILICONE, TANK TO BREW VALVE
21 1 1025.00039.00 TUBE, 5/8" OD X 3/8 ID X 10" LG, DRAIN
22 1 1025.00058.00 TUBE, 9/16"OD X 5/16"ID X 25.00"LG
23 1 1025.00046.00 TUBE, 5/8" OD X 3/8" ID X 5.0" LG, DOUBLE VALVE
24 12 1084.00011.00 NUT, CLIP ON
(
J-NUT
)
, #6-32, 22-20 GA., BLK-PH FINISH
25 1 1001.00425.00 BREW BASKET RAIL, RIGHT, CBS-1220
26 1 1001.00426.00 FRONT COVER, CBS-1221
27 12 1082.00017.00 SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
28 1 1046.00003.00 LABEL, CSD WARNING, 1.5" X 5.0"
29 1 1046.00035.00 LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
30 1 1402.00098.01 HARNESS, LOW AMP, CBS-1131 XV+, UL
31 1 1086.00009.00 CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
32 1 B024230BN2 BREW BASKET ASSY, 9-3/4" X 4-1/2", BROWN PLUG Standard Plastic
33 1 B025230B1 BREW BASKET ASSY, METAL, 9-3/4" X 4-1/2", BLACK Standard Metal
34 1 B014218BN2 BB ASSY, 13" X 5", ınˇ.218" HOLE, BRN PLUG Gourmet Plastic
35 1 B003218B1 BREW BASKET ASSY, 13" X 5", .218 DIA HOLE, BLACK Gourmet Metal
36 1 1086.00008.00 CONNECTOR, CLAMP, NON-METALLIC CABLE, 3/4"
37 1 1063.00016.00 POWER CORD, 120VAC W/NEMA 5-15P PLUG
38 1 1402.00110.00 WIRE HARNESS, CBS-1221, HIGH AMP
39 1 1104.00190.00 TANK ASSEMBLY, CBS-1221, 1.7kW/120V
A
C OR 3.2kW/240VAC
40 1 1102.00445.00
A
SSY, BREW BASKET LOCKER W/FEEDBACK
41 1 1003.00259.00 BRACKET, BREW BASKET LOCK COVER
42 2 1083.00011.00 WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
43 2 1084.00010.00 NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
