15
i) Place the tip/ring cable core ends of the connecting cables on the
terminals located in the section TELEPHONE NETWORK LINES of
the connecting diagram and marked as TIP or RING.
S 11, Figure 6 Connection diagram
In case relay contacts are used
j) Pass and fix the switching contact connecting cables through the
cable entry glands (4).
S 11, Figure 4 Inside view of telephone lower part and mounting
holes
k) Place the cable core ends of the switching contact connecting cables
on the RELAY of the connecting diagram. In the case of a DC-load,
terminals labelled as DC or DC+ must be used; in case of AC switch-
ing load, the two terminals labelled AC ~ must be used.
S 11, Figure 6 Connection diagram
l) Check for proper sealing before placing the upper part of the tele-
phone.
m) Insert the plug connectors (7) of the flat cable into the pin contact
strip (21) of the telephone upper part (1) and place the upper part on
the telephone lower part (3).
n) Fix the telephone upper part (1) with the four cover screws (2).
Device – adjusting sling holder
The holding strength for the handset is continuously adjustable. Loosen
the screws (15) and move the stopping catches (16). Pushing the stop-
ping catches together increases the holding strength whereas pulling
them apart reduces it. Tighten the screws again.
Device – start-up
The ExResistTel telephone is ready for operation as soon as it has been
connected to the telephone network.
Device – maintenance
The ExResistTel telephone contains no parts that have to be main-
tained.
As delivered condition – box contents
The scope of delivery includes:
- ExResistTel telephone
- this operating manual
- 2 self-adhesive lettering
