3 INTERFACING THE PROTONODE TO HOST OEM DEVICE
3.1 ProtoNode RER and LER showing connection ports
Figure 4: ProtoNode RER (left) and LER (right)
3.2 Wiring Connections to ProtoNode RER and LER
ProtoNode 6 Pin Phoenix connector – Pinouts
RS-485 Port for
Serial Field Protocol
LonWorks
Service Pin
LonWorks Port
OEM
Connection
RS-485 Port
Power +/- and FG
9-30 VDC, 12-24 VAC
10/100
BaseT
OEM
Connection
RS-485 Port
Power +/- and FG
9-30 VDC, 12-24 VAC
OEM
Connection
RS-485 Port
