Fimar MPF1,5 - Parts List (MPF;1,5-2,5)

CATALOGO PARTI DI RICAMBIO • SPARE PARTS CATALOGUE • CATALOGUE PIÈCES DE RECHANGE ERSATZTEILKATALOG
Mod. MPF/1,5-2,5
Rif Codice Caratteristiche Descrizione
No Code Characteristics Description
1 CO1300 Cerniera Hinge
2 CO1301 Cerniera Hinge
3 CO1302 (2,5) Gancio Claw
3 CO1341 (1,5) Gancio Claw
4 CO1303 (2,5) Coperchio Cover
4 CO1342 (1,5) Coperchio Cover
5 CO1304 Pomello Knob
6 CO1305 (2,5) Volantino Handwheel
6 CO1343 (1,5) Volantino Handwheel
7 CO1306 (2,5) Elica Screw shaft
7 CO1344 (1,5) Elica Screw shaft
8 CO1307 Piedino Foot
9 CO1308 (2,5) Ghiera Locking ring
9 CO1345 (1,5) Ghiera Locking ring
10 CO1312 230V/1Ph/50Hz (2,5) Motore Motor
10 CO1346 230V/1Ph/50Hz (1,5) Motore Motor
11 CO1321 Microinterruttore Microswitch
12 SL0891 Pulsante Push button
13 CO1316 GUK ø20 (2,5) Ghiera Locking ring
13 CO1348 GUK ø17 (1,5) Ghiera Locking ring
14 CO1317 6204 2RS (2,5) Cuscinetto Bearing
14 SL1799 6004 2RS (1,5) Cuscinetto Bearing
15 CO1318 (2,5) Albero Shaft
15 CO1349 (1,5) Albero Shaft
16 SL0131 6203 2RS (2,5) Cuscinetto Bearing
16 SL2473 6003 2RS (1,5) Cuscinetto Bearing
17 CO1322 (2,5) Guarnizione Gasket
17 CO1350 (1,5) Guarnizione Gasket
18 CO1323 (2,5) Albero Shaft
18 CO1351 (1,5) Albero Shaft
19 CO1324 (2,5) Pannello Panel
19 CO1352 (1,5) Pannello Panel
20 CO1325 (2,5) Supporto Support
20 CO1353 (1,5) Supporto Support
21 CO1326 HTD P5x740 (2,5) Cinghia Belt
21 CO1354 HTD P5x580 (1,5) Cinghia Belt
22 CO1327 (2,5) Puleggia Pulley
22 CO1355 (1,5) Puleggia Pulley
23 CO1328 (2,5) Coperchio Cover
23 CO1356 (1,5) Coperchio Cover
24 CO1329 (2,5) Ingranaggio Gear
24 CO1357 (1,5) Ingranaggio Gear
25 SL1799 6004 2RS (2,5) Cuscinetto Bearing
25 SL2473 6003 2RS (1,5) Cuscinetto Bearing
26 CO1331 (2,5) Guarnizione Gasket
26 CO1358 (1,5) Guarnizione Gasket
27 CO1332 (2,5) Albero Shaft
27 CO1359 (1,5) Albero Shaft
28 CO1333 (2,5) Carcassa Housing
28 CO1360 (1,5) Carcassa Housing
29 CO1334 (2,5) Copertura Covering
30 CO1336 (2,5) Contenitore Tank
30 CO1362 (1,5) Contenitore Tank
31 CO1337 230V/1Ph/50-60Hz Scheda elettronica Electronic card
32 CO1340 (2,5) Ingranaggio Gear
32 CO1330 (1,5) Ingranaggio Gear
33 CO1319 51105 (2,5) Cuscinetto Bearing
33 CO1320 7204 (1,5) Cuscinetto Bearing
34 SL0202 6005 2RS (2,5) Cuscinetto Bearing
34 SL1799 6004 2RS (1,5) Cuscinetto Bearing
35 SL0202 6005 2RS (2,5) Cuscinetto Bearing
35 SL2473 6003 2RS (1,5) Cuscinetto Bearing
36 CO2048 (2,5) Chiave Key
36 CO2049 (1,5) Chiave Key
37 CO2046 (2,5) Fondo Bottom
37 CO2047 (1,5) Fondo Bottom
38 CO2050 (2,5) Puleggia Pulley
38 CO2051 (1,5) Puleggia Pulley
39 SL1671 1Ph+N+Gnd Cavo elettrico Electric cable
40 CO2052 (2,5) Coperchio Cover
(*): fuori produzione / out of production
