FINE MECHATRONICS FS8000
30
CHAPTER 5. SET-UP ILLUSTRATION
5-1.
BASIC FUNCTION FOR WEIGHING
F00-
S&C MODE
전환
SET UNIT WEIGHT
kg
F01-
1
ton
WEIGHT BACK-UP
NORMAL
F02-
1 BACK-UP
※ NORMAL Condition is unavilable to back up the weight on the weighing part
In No power or OFF So,please turn on the power after removing it
※ BACK-UP menas that the weight weighing in OFF keeps the weight
When the power turns on
(KEY) Set BACK-UP MODE after adjusting the weight on NORMAL condition
SET ZERO TRACKING RANGE
0 No ZERO TRACKING
0.5DIGIT / 0.25sec
2 1DIGIT / 0.25sec
F03-
3 2DIGIT / 0.25sec
※ What is ZERO Tracking ?
If A weight continue to change with a small value,
It displays the weight in spite of No product on the weighing part.
It is to compensate such a value.
SET SAFTY MOTION BAND
0 0.5 Devision
1 Devision
2 2 Devision
3 4 Devision
F04-
4 8 Devision
※ Motion Band ?
It means compensating a
termpoary tramble
If the weight change was less than
the present set value for the time set
by F-08, it will be a safty jusding.
When the weight change`s difference was in the range set for a time,
This function will make it safty.
If the factory environment have much vibration,pleae enlarge the motion band.
Also,if it was lower,please make it smaller.
To Next Page
