FINE mechatronics FS-8000 - 5-4-3 OPTION-05;06 Analog Out Setup

---------------------------------------------------------------------------------
FINE MECHATRONICS FS8000
46
5-4-3 OPTION-05/06 ANALOG OUT
* This option is a device to output and convert the weight value to External device(Recorder P.L.C
Center control so) controlled by Analog Signal.
* The voltage output occurs proportionallly the voltage according to the size of weight in 0V ~10V.
* The current output occurs proportionallly the current according to the size of weight in 4mA~20mA
* The precision of Analog output is Max.1/3000
So,Unavailable to use it in case of high precision over 1/3000
Analog Out Weight Selecting

displayed Weight value
1 GROSS Weight
F60-
2 NET Weight
Gross or Net Weight can be different with weight value displayed
Analog Out standard Selecting

MAx.Weight Standard
F61-
1 Standard value setup by F-63
Analog Out POLARITY

Positive out : 4mA, 0V while weight is 0
F62-
1 Negative out : 20mA, 5V, 10V while weight is 0
Analog Out Standard Weight Selecting.
F63-
Analog max out value when weight setup.
* first Setting
000000
