LUBRICATION CHART
Ref. No. Location Lubricant Frequency Number
1 Conveyor Bearings (Idle and Drive) CL Weekly 4
2 Feed Roll Bearings (Idle and Drive) CL Weekly 2
3 Blower Bearings CL Weekly 2
4 Air Lock Bearing CL Daily 1
5 Wheel Bearings CL Annually 4
6 Check Oil Level-Blower BO Daily 1
Change Oil-Blower BO Annually 1
7 Check Fuel Level DF Daily 1
8 Check Hydraulic Oil Level HO Daily 1
Change Hydraulic Oil and Filter HO Seasonally 1
9 Change Engine Oil and Filter MO See Engine Manual 1
10 Check Engine Oil Level MO Daily 1
11 Change Engine Coolant AF Seasonally 1
12 Check Coolant Level AF Daily 1
13 Check Air Cleaner-Engine Daily 1
14 Check Air Cleaner-Blower Daily 1
15 Gear Box Air Lock GO Seasonally 1
LUBRICANT OR FLUID USED
CL Chassis Lubricant
MO Motor Oil SAE 10W-40
AF 50/50 Anti Freeze and Water
DF Diesel Fuel
HO Hydraulic Oil, Gulf 46AW, Mobile DTE25, or Shell Tellus 46
GO 90 W Gear Oil
BO Mobil SHC 630
TIME KEY
Daily (8 Hours)
Weekly (40 Hours)
Seasonally (500 Hours)
Annually (2000 Hours)
See Engine Manual
FLUID CAPACITIES
Fuel -15 gal (57 L)
Hydraulic Oil -15 gal (57 L)
Engine Coolant -1.5 gal (6 L) 50/50 Mix Only
Engine Oil - 6 qt (6 L)
Gear Box Oil - 9 oz (.26 L)
