AIR LOCK PARTS
Ref. No. Part Number Description No. Req’d
055653 Air Lock Assembly 1
1 055721 Inlet Seal Plate 1per
2 055694 3/8-16 UNC X 3/4 Lg. Low Profile Soc Hd Bolt 8per
3 055148-01 1/32" Thick Style 50 Gasket A/R
4 055148-02 1/16" Thick Style 50 Gasket A/R
5 055148-03 1/64" Thick Style 50 Gasket A/R
6 055148-04 0.006" Thick Style 50 Gasket A/R
7 055720 Outlet Seal Plate 1per
8 055552 Hydraulic Motor 1per
9 055517 Motor Gasket (Not Shown) 1per
10 055464 Air Lock Gearbox 1per
11 X08060SH 1/2-13 X 3-3/4" Lg. Soc Hd Cap Bolt 4per
12 055464-1B Gearbox Lip Seal (Not Shown) 1per
13 055700 Gearbox Slinger Seal 1per
14 055580 Inlet Flanged Gearbox Mount 1per
15 052139-03 Spacers (Must be within 0.002" of ea. other) 4per
16 055439-02 Air Lock Inlet End Plate 1per
18 055423 Finished Rotor 1per
19 Z0408 1/4-20 UNC X 1/2" Lg. Set Screw (Not Shown) 2per
20 055463 Hex Plug (Not Shown) 2per
21 055402 Hardened Rotor Key (Not Shown) 1per
22 055644 Air Lock Housing 1per
23 052103 Air Lock Outlet Plate 1per
24 055579-03 Air Lock Mounting Foot 1per
25 005446 Rotor Shaft Bearing 1per
26 F302-0003-01 Bearing Seal 1per
27 055113 Chipper Knife 1per
28 XS0444 Chipper Knife Alignment Screw (Not Shown) 4per
29 055440 Plastic Shim A/R
30 055597 Discharge Insert 1per
31 055619-01 Right Hand Deflector 1
32 055623-02 Deflector Skirt (Not Shown) 2
33 055619-02 Left Hand Deflector 1
35 055635-01 Air Lock Seal Angle w/Knife 1
36 055635-02 Air Lock Seal Angle w/o Knife 1
37 055440-01 Discharge Elbow Gasket 1
38 055630 Disharge Elbow 1
39 055374 Hose Adapter 1
40 F302-0005 Knife Screw Cover 1
27
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
