LBBB302-MMA
25
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
AXLE AND HUB PARTS
Ref. No. Part Number Description No. Req’d
055789 Axle Assembly 2
1 055789-11 Hub 2
2 055789-13 Outer Bearing Cup 2
3 055789-15 Spindle Washer 2
4 055789-18 Grease Cap 2
5 055789-19 Rubber Plug 2
6 055789-17 Cotter Pin 2
7 055789-16 Spindle Nut 2
8 055789-14 Inner Bearing Cone 2
9 055789-12 Bearing Seal 2
10 055789-8 Left-Hand Brake Assembly 1
055789-9 Right-Hand Brake Assembly 1
11 055789-10 Nut 8
