USE AND MAINTENANCE MANUAL
Road Sweeper S150
Page 22 of 54
3.5.
OPERATING PRINCIPLES OF THE SWEEPER
The front brushes and the third brush convey the trash and head it towards the suction mouth.
The turbine generates a depression in the closed waste container, thus creating a suction effect
in the suction mouth.
Dust removal is obtained through a water system. The water is pumped towards the nozzles,
located on the brushes and on the suction mouth and hose.
In the waste container, the water seeps through the grating at the bottom of the hopper. From
there it is returned without pressure to the suction mouth and then re-used to remove dust. This
is called water recycling system.
