USE AND MAINTENANCE MANUAL
Road Sweeper S150
Page 35 of 54
4.9.
WATER SYSTEM
Picture 17
Picture 18
On the brush and suction mouth are nozzles for spraying water allowing dust removal. [See
Picture 17].
Operation
Operate the water pump by pressing the button POS 1 [See Picture 18], open the taps POS 3,
4, 5 [See Picture 18] to adjust the water flow.
WARNING
When the water tank is empty on the dashboard the relevant warning light turns on
pos. 21 Table 3.3. Immediately turn off the water pump to prevent it from
suffering faults.
